Ignition Button Box - MINI RR T

Large, premium quality mechanical buttons with sharp, saturated Red LED Rings. Flat surface, deep press, defined mechanical feel.
Smaller and lower profile enclosure with VESA 75 x 75 mm built-in M4 threaded inserts.
17 inputs.

• Premium mechanical buttons (metal) with Red Ring LEDs -8pcs
• Non-momentary (no spring return) mini toggle -LED power switch
• Non-momentary (no spring return) OFF-ON toggle paired with blinking LED indicator below -may require custom in-game assignment, or external software for proper operation - SVMapper/ Joy2Key / AutoHotK
• Momentary (spring return) OFF-(ON) toggle with safety cover
• Momentary (spring return) (ON)-OFF-(ON) two-way toggle
• Large "Engine Start" button (non-backlit)
• Momentary (spring return) (ON)-OFF-(ON) two-way toggle LEFT-RIGHT
• Momentary (spring return) (ON)-OFF-(ON) two-way toggle
• Powder Coated, All-Metal Enclosure with 4 built-in M4 threads (VESA 75x75mm centered on the backside) for direct hard mounting.

• Enclosure dimensions: 157 x 183 x 28 mm
  Weight: 980g

• Connection: Internally connected (non detachable) 1,7m USB cable routed from the backside.



•


• - 6 industry grade CTS rotary encoders (stiff Version Left/Right - rotation)

  - 10 tactile feel mechanical push-buttons with red LEDs

  - Non-momentary (no spring return) mini-toggle -LED power switch

  - Non-momentary (no spring return) Off-ON toggle (paired with blinking LED indicator below) -may require external software for proper operation - SVMapper/ Joy2Key / AutoHotKey...

  - "Engine Start" (non backlit)

  - Four-way Joystick Switch (4 inputs) -this is not analog joystick!

  - Momentary (spring return) Off-(on) toggle with safety cover

  - Momentary (spring return) (on)-Off-(on) two way toggle

  - Non-momentary (no spring return) Off-ON toggle -may require - external software for proper operation - SVMapper/ Joy2Key / AutoHotKey...

  - Powder Coated, All-Metal Enclosure.

  - 4 built-in metric M4 threads (centered on the backside) - non-VESA! (100x155mm) for direct hard mounting

  - Includes 175 x 120 x 8 mm adapter plate allowing easy VESA 100 x 100 mm mounting (1x 3D printed mounting plate 175 x 120 x 8 mm, 4x Hex Head Screw M5x16, 4x Hex Socket Head Screw M4x12, 4x Washer Spacer M4, 4x Hex Lock Nut M5).

  - Enclosure dimensions: 154 x 254 x 33 mm

  - Weight: 1300g

  - Connection: USB Type B plug, USB cable included
